WDUV250-12A large format shiny color digital Printing Machine fit Small Quantity Orders with UV ink

Short Description:

WDUV250-12A Muti Pass large format high quality digital UV inkjet printing machine, use UV curable ink, printing width max 2500mm, length no limit, printing speed up to 230 ㎡/h, production efficiency around 80~250 PCS/H, fit small and personalized orders which want shiny color.

Send email to us Download as PDF

Product Detail

Product Tags

Description

1.WDUV250 series digital printing machine, without plate, without cleaning, using CMYK+M color printing mode, convenient, environmental protection with low carbon.

2. The Printhead temperature system, can effectively overcome the various low temperature environment.

3. Using stronger servo motor with high precision reducer, higher precision, faster speed, more stable performance.

4. Use 6 grade super high precision gear and high precision cylindrical grinding power roller, drive more accurately.

5. Strong rail beam, Mute guide rail,Printing flat error less than 0.2mm, makes the print more stable and higher accuracy.

6. New printhead cleaning mode, automatic cleaning,saving ink, printing more frequency.

7.Print on-demand without creating waste ink,thus achieving lower consumption and better environmental protection.

8. Rapid for the orders change. Lower printing cost to run from 1+ sheet. Instant service to the customer for rush orders.

Applications:

Digital printing on corrugated carton board,honey-board,wooden board,coated board and other hard materials.

Included marks,NO.,advertising pictures

Specifications:

Article NO.	WDUV250-12A
Printhead	Piezoelectric high-procision printhead
Printhead quantity	12 pieces
Ink type	Special UV curable ink
Color model	Cyan,Magenta,Yellow,Black,White
Medium distance	2mm-4mm
Printing resolution	≥360*600 dpi
Printing efficiency	WDUV250-12A Max 230㎡/H with 2 pass
Media type	Hard materials such as: cardboard,wood,glass,tiles,metal plate,acrylic board,plastic,etc.
Printing format	Below 2500mm*1350mm under auto feeding
Drying speed	Dry once print out
Working environment	15ºC-32ºC Indoor，Humidity 40%-70%
Ink supply	Automatic continuous ink supply
Feeding mode	Automatic feeding
Material thickness	1.5mm-35mm（max can be ordered to 50mm)
Thermostat system	Thermostat system with patent
Operate system	Professional RIP system,professional printing system,Win7 system with 32 bit operating system or above
Power supply	About 18 KW power：AC380±10%，50-60HZ
Machine size	LWH：473061001751(mm)
Weight	5300KGS
